2P, 30 FLA / 40A Max 220V – 240V AC Contactor : AFTC-CTN-100

This image displays the technical details of a Definite Purpose (DP) Magnetic AC Contactor used primarily for heavy electrical switching loads, such as central air conditioning compressors, motors, and heating systems.

• Model Number: AFTC-CTN-100 (Series C)
• Number of Poles: 2P (Two-pole configuration)
• Current Rating (Full Load Amps): 30 FLA / 40A Max (The text on the faceplate explicitly notes 30FLA and 30/40A, whereas the previous unit was a 40 FLA / 50A model).
• Operating Voltage: 240V / 277V AC
• Coil Voltage: 220V – 240V AC at 50/60 Hz
• Torque Specification: 20 lb-in using copper wire (CU 75°C WIRE)

• Top Module: Line terminal inputs (L1, L2) and load output terminals (T1, T2).
• Bottom Module: Electromagnetic actuator base showing the 220V control coil component
