3/8 inch L-Type R-410A Service Valve : AFTC-SAS-017
This model increases the connection diameter while maintaining the angled L-Type geometry and full compatibility with high-pressure, modern eco-friendly refrigerants.
📋 Technical Specifications
- Model Number:
AFTC-SAS-017 - Component Type: Split Air Conditioner Service Valve (3-Way)
- Size: 3/8 inch (Commonly used on the liquid line of medium-to-large residential split systems, or the suction side of small mini-splits).
- Design Profile: L-Type (Features a 90-degree curved copper pipe extension designed for corner-entry or side-access outdoor unit casings).
- Refrigerant Compatibility: R-410A (Heavy-duty brass construction reinforced to safely handle the high operating pressures of R-410A systems).
🔍 Structural Design & Connections
- Curved Copper Extension: The 3/8″ bent copper tube on the left brazes straight into the interior condenser coils. A protective plastic cap keeps out moisture and dust prior to installation.
- Integrated Mounting Plate: Features a built-in brass mounting ear with an oval screw hole to secure the valve body flush against the outdoor unit’s metal chassis.
- Main Line-Set Flare Port: The large brass threaded connection facing upward features a pre-fitted 3/8″ flare nut to lock down the external copper line-set.
- Service Access Port: The smaller threaded Schrader port facing downward allows technicians to attach high-pressure manifold gauge hoses to pull a vacuum, purge lines, or charge the system.
- Valve Isolation Stem: The heavy hexagonal brass cap on the far right seals off the internal Allen wrench port used to capture or release the refrigerant charge inside the condenser.
📞 Contact & Procurement Details
To secure pricing, check stock availability, or coordinate bulk fulfillment across Saudi Arabia, contact the Ayub First Trading Company distribution offices directly:
- Primary Hotline (Call/WhatsApp): +966 56 004 2170
- Email Inquiries: ayubfirsttrading@gmail.com
- Corporate Web Platform: ayubfirsttrading.com
- Regional Warehouses: Showrooms fully stocked in Riyadh (Al Jabrah, Batha Road), Jeddah, Dammam, and Al Khobar (20th Street, Hail Road).
Description
Description
This model increases the connection diameter while maintaining the angled L-Type geometry and full compatibility with high-pressure, modern eco-friendly refrigerants.
📋 Technical Specifications
- Model Number:
AFTC-SAS-017 - Component Type: Split Air Conditioner Service Valve (3-Way)
- Size: 3/8 inch (Commonly used on the liquid line of medium-to-large residential split systems, or the suction side of small mini-splits).
- Design Profile: L-Type (Features a 90-degree curved copper pipe extension designed for corner-entry or side-access outdoor unit casings).
- Refrigerant Compatibility: R-410A (Heavy-duty brass construction reinforced to safely handle the high operating pressures of R-410A systems).
🔍 Structural Design & Connections
- Curved Copper Extension: The 3/8″ bent copper tube on the left brazes straight into the interior condenser coils. A protective plastic cap keeps out moisture and dust prior to installation.
- Integrated Mounting Plate: Features a built-in brass mounting ear with an oval screw hole to secure the valve body flush against the outdoor unit’s metal chassis.
- Main Line-Set Flare Port: The large brass threaded connection facing upward features a pre-fitted 3/8″ flare nut to lock down the external copper line-set.
- Service Access Port: The smaller threaded Schrader port facing downward allows technicians to attach high-pressure manifold gauge hoses to pull a vacuum, purge lines, or charge the system.
- Valve Isolation Stem: The heavy hexagonal brass cap on the far right seals off the internal Allen wrench port used to capture or release the refrigerant charge inside the condenser.
📞 Contact & Procurement Details
To secure pricing, check stock availability, or coordinate bulk fulfillment across Saudi Arabia, contact the Ayub First Trading Company distribution offices directly:
- Primary Hotline (Call/WhatsApp): +966 56 004 2170
- Email Inquiries: ayubfirsttrading@gmail.com
- Corporate Web Platform: ayubfirsttrading.com
- Regional Warehouses: Showrooms fully stocked in Riyadh (Al Jabrah, Batha Road), Jeddah, Dammam, and Al Khobar (20th Street, Hail Road).
