3P,60 FLA / 70A Max 24V AC CONTACTOR : AFTC-CTN-119
This model retains the high-capacity 60A/70A 3-Phase power handling of the previous unit but introduces a critical change in coil voltage, shifting to low-voltage automation control.
📋 Technical Specifications
- Model Number:
AFTC-CTN-119 - Number of Poles: 3P (Three-pole configuration for heavy-duty commercial or industrial systems)
- Current Rating: 60 FLA (Full Load Amps) / 70A Max resistive load per pole.
- Control Coil Voltage: 24V AC at 50/60 Hz (⚠️ Crucial change: Unlike the 220V
CTN-118model, this unit relies on a low-voltage 24V control signal, typically powered by a step-down transformer inside modern control circuits or HVAC thermostats).
⚡ Horsepower & Load Breakdown
The faceplate parameters detail the massive motor load and locked rotor amp (LRA) capacities for this industrial model:
- At 240V AC: Handles up to 360 LRA (Locked Rotor Amps).
- 1-Phase Power: Rated up to 5 HP (Horsepower).
- 3-Phase Power: Rated up to 10 HP.
- At 480V / 600V AC: Handles up to 300/240 LRA.
- 3-Phase Power: Rated up to 15 HP.
- At 120V AC:
- 1-Phase Power: Rated up to 2 HP.
🔧 Installation Mechanics
- Terminals: 1L1, 3L2, 5L3 for high-current incoming lines; 2T1, 4T2, 6T3 for the heavy machinery/motor outputs.
- Terminal Screw Torque: 20 lb-in using copper wire (
Cu 75°C wire). - Lug Set Screw Torque: 40 lb-in.
📞 Contact & Procurement Details
To secure pricing, check stock availability, or coordinate bulk fulfillment across Saudi Arabia, contact the Ayub First Trading Company distribution offices directly:
- Primary Hotline (Call/WhatsApp): +966 56 004 2170
- Email Inquiries: ayubfirsttrading@gmail.com
- Corporate Web Platform: ayubfirsttrading.com
- Regional Warehouses: Showrooms fully stocked in Riyadh (Al Jabrah, Batha Road), Jeddah, Dammam, and Al Khobar (20th Street, Hail Road).
