YM-800 XPG Universal Washing Machine PCB: YM 800
This image shows the YM-800 XPG Universal Washing Machine PCB kit, an aftermarket replacement control system specifically designed for fully automatic front-load (drum) washing machines.
Kit Components
- Main PCB Board: The central “brain” that coordinates functions like water filling, spinning, and timing.
- Digital Control Panel: Features a large LCD display and physical buttons for Power, Speed, Water Temperature (WT), Delay, Soak, Program selection, and Start/Pause.
- Pressure Switch (Water Level Sensor): An electronic sensor that monitors and regulates water levels.
- Wiring Accessories: Includes a ribbon cable for connecting the panel to the board and five terminal connectors for internal machine wiring.
Key Features & Functions
- Universal Compatibility: Designed to replace original boards in various front-load brands like Samsung, LG, and Whirlpool.
- Advanced Controls:
- Multiple Programs: Offers up to 10 wash cycles (e.g., Standard, Strong, Fast, Soft).
- 8-Stage Water Level: Allows for precise, water-saving electronic adjustment.
- Memory Function: Remembers the last selected program to resume after power interruptions.
- Safety Features: Includes automatic fault alarms for unbalanced loads or water flow issues and an auto-power off function upon cycle completion.
Description
Description
This image shows the YM-800 XPG Universal Washing Machine PCB kit, an aftermarket replacement control system specifically designed for fully automatic front-load (drum) washing machines.
Kit Components
- Main PCB Board: The central “brain” that coordinates functions like water filling, spinning, and timing.
- Digital Control Panel: Features a large LCD display and physical buttons for Power, Speed, Water Temperature (WT), Delay, Soak, Program selection, and Start/Pause.
- Pressure Switch (Water Level Sensor): An electronic sensor that monitors and regulates water levels.
- Wiring Accessories: Includes a ribbon cable for connecting the panel to the board and five terminal connectors for internal machine wiring.
Key Features & Functions
- Universal Compatibility: Designed to replace original boards in various front-load brands like Samsung, LG, and Whirlpool.
- Advanced Controls:
- Multiple Programs: Offers up to 10 wash cycles (e.g., Standard, Strong, Fast, Soft).
- 8-Stage Water Level: Allows for precise, water-saving electronic adjustment.
- Memory Function: Remembers the last selected program to resume after power interruptions.
- Safety Features: Includes automatic fault alarms for unbalanced loads or water flow issues and an auto-power off function upon cycle completion.
