LG Small. Auto Metal Clutch Gear: AFTC-DFS-002
This part is an AFTC-DFS-002 Auto Metal Clutch Gear (Gearbox) specifically designed for LG Small Top-Load Fully Automatic washing machines with a capacity of 6kg to 10kg.
Key Technical Specifications
The image provided contains precise engineering measurements for compatibility:
- Top Shaft Dimensions: Features a split-segment shaft with a 27mm upper portion and a 28mm lower portion.
- Upper Flange Diameter: The widest part of the metal housing measures 255.5mm.
- Base Pulley Diameter: The bottom pulley is 106mm wide.
- Model/Internal Part Number: DFS-7F5A.
Functional Details
- Gear Mechanism: This assembly uses a “Double Gear” (or Twin Gear) system. The white plastic gears at the base are visible in the image. This design ensures smooth torque transmission and stable drum movement during both wash and spin cycles.
- Compatibility: It is an original equipment (OE) type replacement part compatible with LG machines featuring Fuzzy Logic and TurboDrum systems. It is typically used in models with a flat belt pulley system.
- Material: The unit is constructed from iron and stainless steel, featuring a durable silver-tone metal housing for high-stress applications.📞 Contact & Procurement Details
To secure pricing, check stock availability, or coordinate bulk fulfillment across Saudi Arabia, contact the Ayub First Trading Company distribution offices directly:
- Primary Hotline (Call/WhatsApp): +966 56 004 2170
- Email Inquiries: ayubfirsttrading@gmail.com
- Corporate Web Platform: ayubfirsttrading.com
- Regional Warehouses: Showrooms fully stocked in Riyadh (Al Jabrah, Batha Road), Jeddah, Dammam, and Al Khobar (20th Street, Hail Road).
